6KW - BATTERIES LFP - 14.3 KWH - IP66

ESS-M ALL-IN-ONE RESIDENTIAL SYSTEM

All-in-one residential solution — 6 kW SiC inverter + 280 Ah / 14.3 kWh IP66 LFP battery

The EAD-ESS-M combines a 6 kW hybrid inverter and a 14.3 kWh LFP battery in a single reference. Its grade A 280 Ah battery, guaranteed for more than 8,000 cycles, delivers 12.9 kWh usable at 95% depth of discharge. Rare in this segment, its battery is IP66 protected and installs outdoors without any additional housing.

6 kW SiC inverter + 14.3 kWh LFP battery
12.9 kWh usable at 95% DoD — ≥ 8,000 cycles
On/off-grid switching < 10 ms
IP66 battery — outdoor installation

IP66CE certified10-year warranty

Request a quote for this product Contact us Download the datasheet

Prices shared on simple quote request · Reply within 24–48 hours.

Highlights

Key day-to-day benefits.

20-year design life

97.5% European efficiency — 98% max

Scalable: 2nd battery → 28.6 kWh

Inverter & battery warranty: 10 years

Versus the competition

ESS-M ALL-IN-ONE RESIDENTIAL SYSTEM — residential storage

In the residential hybrid inverter segment, many market solutions require you to buy the inverter and battery separately, verify their compatibility, then make them coexist on the same wall.

One block, one reference

The EAD ESS range and the EAD-ESS-M integrate the inverter and battery in a single enclosure — less wiring, less configuration, fewer points of failure than a self-assembled architecture with separate components.

Low-frequency technology on the EAD ESS range

A design recognised for its industrial robustness and its ability to deliver 3× the nominal power at peak — a real advantage to start demanding loads (motors, pumps) without difficulty in backup mode.

IP66 on the EAD-ESS-M battery

A rarity in this price segment, allowing outdoor installation without additional protective housing.

Datasheet

Full specifications.

Inverter — nominal / off-grid power	6,000 W / 6,000 W (27.2 A)
Inverter — PV input	9,000 Wp max · 600 V max · 2 trackers / 1 string · MPPT 80–550 V
Inverter — European / max efficiency	97.5% / 98.0% (SiC technology)
Inverter — on/off-grid switching	< 10 ms
Inverter — AC output	220/230/240 V · 50 Hz · THDi < 3%
Inverter — protection / dimensions	IP65 — 500 × 470 × 180 mm — 21 kg (wall-mounted)
Inverter — monitoring	LED / App / Wi-Fi / 4G / Bluetooth — RS485 / CAN / DRED
Battery — capacity	14.3 kWh nominal (12.9 kWh usable, 95% DoD)
Battery — cells	LFP 280 Ah grade A — 51.2 V nominal
Battery — charge / discharge current	100 A std / 140 A max
Battery — cycles / design life	≥ 8,000 cycles / 20 years
Battery — protection / dimensions	IP66 (outdoor) — 525 × 297 × 935 mm — 99 kg
Scalability	2nd battery → 28.6 kWh (recommended configuration)
Certifications	CE · IEC 62109-1/2 · EN 61000-6-x · EN 50549-1/-10 · VDE-AR-N 4105 · IEC 62619 · UN 38.3
Warranty	10 years inverter · 10 years battery
Technology	Mango Power — Shenzhen Xihe Future Technology (exclusive to EAD in France)

Technical data is provided for guidance only and may change without notice.

Good to know

Delivery, warranty & after-sales.

European delivery

Stock available in Europe for most references. Lead times and terms confirmed on quote.

Certified & guaranteed

CE certification, manufacturer warranty and technical documentation shipped with every product.

After-sales & spare parts

Our team handles technical after-sales support and the supply of spare parts.

The price? The price of this product is shared after we receive your quote request. Our team replies with a personalised price, the detailed technical sheet and the delivery terms.
